The Detector for Loop Coil of Parking Barrier.



1ch vehicle detector(SP-L102 ), 2 ch vehicle detector  (SP-L202 )



A. Product Overview

When a car (metal object) enters the entry/exit lane of a parking lot, the frequency of the

buried Loop Coil is modulated.

It is a device that detects and operates equipment connected to the detector with the

corresponding relay contact signal ( 99%).

B. Features

1. Frequency can be determined with just a beep sound without any special equipment.

2. Loop coil frequency can be easily changed by manipulating the DIP switch.

3. A total of 2 relays are built-in and can be linked separately with 2 devices.

(Non-voltage relay contact point)

4. A total of 16 levels of sensitivity adjustment function ( 0 ~ F )

5. Relay output time can be adjusted from 1sec to 60sec.

6. With built-in A.F.C. function, no separate settings are required even in climate change

and high humidity.

7. Relay contact point can be selected for output when vehicle detection starts and

output when detection is stop.

8. Terminal block type (SP-L102) and connector type (SP-L202) can be selected.
